The first two chapters of the book Enterprise Flexible Rails are done.

The code for the completed book chapters is at http://github.com/peterarmstrong/enterprise_flexible_rails/tree/master and at http://github.com/dima/enterprise_flexible_rails/tree/master.

Now, since Dima and I are writing this book in the style that I wrote Flexible Rails, we have a “goal app” we are building, and the book is the process of retracing our steps.  The goal app is once again called “Pomodo”, but it’s much better than the “Pomodo” of Flexible Rails — this one will almost be at the level of a commercial product.  (In fact, we will be building a commercial product on top of the book code.)

The reason I am talking about the Pomodo app is that (as you will see if you read the book) the code for the Pomodo app is currently about 3-5 chapters ahead of the book text.  However, the Pomodo code is very
instructive to look at, in order to learn the Ruboss Framework before the book chapters are caught up.

To get the latest version of the Pomodo app code, go to http://github.com/dima/pomodo_on_rails.  (Dima’s version will usually be ahead of mine.)

Since the Pomodo app is a few weeks away from being discussed in Enterprise Flexible Rails, here’s the short version of how to get it and follow along.  If this doesn’t make any sense, please post a question to the http://groups.google.com/group/ruboss-framework group:

$> git clone git://github.com/dima/pomodo_on_rails.git
$> cd pomodo_on_rails
$> git submodule init
$> git submodule update

If you haven’t already added gems.github.com to sources to:

$> gem sources -a http://gems.github.com

If you don’t have rubyist-aasm gem installed then do:
$> sudo gem install rubyist-aasm

If you don’t have ruboss4ruby gem installed then do:
$> sudo gem install ruboss4ruby

Then:

$>rake db:refresh
$> ./script/server

At this point, your Rails app is running.

Next, you need to get the Ruboss Framework:

$> git clone git://github.com/dima/ruboss_framework.git

At this point, you import the pomodo_on_rails and the ruboss_framework projects into Flex Builder 3.

You then need to edit the properties of the pomodo_on_rails project (right-click on it, choose Properties, select Flex Build Path, Library Path and then first remove and then re-add the ruboss project. (Flex Builder gets confused otherwise.)  There’s an easier way involving using a compiled SWC, but I like this way since it lets you build from source.

Now that the project is all set up, do a clean build and run the Pomodo.mxml application in the pomodo_on_rails project. You can either login as “dima” with password “monkey”, or you can

sign up. If you are signing up make sure that you check log/development.log for activation URL. Copy-paste that activation URL into your browser, then log in. The application is not fully configured to mail stuff out (on purpose).

That’s it!

You will see the following login screen:
http://ruboss.com/wp-content/uploads/2008/10/efrpomodologin.png

If you login, you will see the following app:
http://ruboss.com/wp-content/uploads/2008/10/efrpomodoapp.png

The more complete explanation will be found in Enterprise Flexible Rails.

These are some screenshots of the Pomodo application we are building for Enterprise Flexible Rails.  Instructions on how to follow along coming soon!

Login:

Main app:

We’re all about simplicity at Ruboss (who isn’t these days?), but the generated Ruboss views have been a bit more complicated than they should have been.  We’ve fixed this now: the image below shows a generated application produced by the new Ruboss generators.

This application is produced by following along with the new Ruboss tutorial here.

–

Edit 2008-11-19 to point at the new ruboss4ruby gem.

Summary:

• Flex = Free, AIR = $499
• $100 off in July with “thanks_early_adopters” coupon code
• buy it at http://ruboss.com/store/

I’m really proud to announce that version 1.0 of the Ruboss Framework is now released!

As described at http://ruboss.com/licensing/, it’s dual-licensed under the GPL v3 and a commercial license.

Briefly, this means that it’s free for in-browser Flex development, but if you want to use it for AIR development you need to buy a commercial license or release your AIR application source code under a GPL-compatible Open Source license. (If your legal department doesn’t like you using GPL’d code for in-browser Flex apps, we’re more than happy to sell you a commercial license – it covers in-browser Flex apps too.)

You can buy licenses at http://ruboss.com/store/.  The commercial license prices are (in USD):

For the month of July only, use the coupon code “thanks_early_adopters” and get $100 off. We are really grateful for the support so far, and we know the documentation situation is a little sparse right now. So, this is our way of not only saying thanks but also funding the documentation effort.

(For group licenses, use the coupon code “thanks_early_adopters20″ to get 20% off, which is better for multiple licenses.)

This is a developer license: there are NO deployment costs.

We feel this is a fair pricing structure that should be attractive to individual consultants, small startups and larger companies. We have worked very hard on the Ruboss Framework, and buying licenses directly funds its future development.

This is just the beginning of the Ruboss Framework story. Next up, we’re going to add Merb integration.

Our upgrade policy is simple:
Commercial licenses get all minor versions (e.g. 1.1, 1.2) free, and get all subsequent major versions (e.g. 2.0, 3.0) for 50% off.

So, please feel free to…

• learn more at http://ruboss.com/
• check out the framework at http://github.com/ruboss
• read the free documentation at http://github.com/ruboss/ruboss_framework/wikis
• buy a license at http://ruboss.com/store/

Thanks,
Peter Armstrong

P.S. Now that we’ve shipped 1.0, we’ll get back to work on the free documentation and the Ruboss book (Enterprise Flexible Rails, at http://manning.com/armstrong2/, which is the definitive Ruboss tutorial).  Don’t worry, we’re going to devote a ton of time to producing free documentation, some of which will be used as the basis of the content in Enterprise Flexible Rails.  (The job of the Ruboss Framework is not to sell Enterprise Flexible Rails; it’s the job of Enterprise Flexible Rails to sell the Ruboss Framework.)

Updated instructions for getting started with the Ruboss Framework are available here. This allows you to work directly with any of our github repositories and such requires Rails2.1 and Git to be installed before you can proceed.

Dima

You can now follow Ruboss Framework development on GitHub and get your hands dirty too if you feel like it.

If you are using Rails 2.1 you can install the Ruboss plugin directly from the GitHub repository. The updated “Hello Ruboss” tutorial is avaiable in the README file.

You can follow development of the main Ruboss branches on GitHub. The most current and official development version (as well as the wiki, etc) will be on Dima’s GitHub account. You can also see Peter’s GitHub account for another development version.

If you want to fork and follow someone’s version of Ruboss Framework, we recommend you follow Dima.

Git and GitHub make it extremely easy to fork, modify and patch other people’s code. Here’s a quick intro to get you started: How to Use GitHub to submit a patch.

(If none of this makes any sense, go to GitHub and see their helpful guides.)

Have fun!

Dima Berastau

[Edited by Peter on 2008-06-15: we are no longer using a separate Ruboss account, since that's not the correct thing to do on GitHub.  Dima's version is the official version of the Ruboss Framework, since Dima is the lead developer.]

I’ve added a swfobject helper to the Ruboss plugin that does a few things for you:
1) It adds a cache-breaking time stamp to the .swf’s url so that you and your users don’t have to refresh their caches when your .swf changes.
2) It allows you to pass Ruby hashes for the flashVars, params and attributes parameters.
3) It will automagically create the flashContent div for you if you want

Here’s what a basic call would look like:

<html>
<head>
    <title>some page</title>
    <%= javascript_include_tag '/bin/swfobject' %>
</head>

<body>
<%= swfobject('/bin/YourSwf.swf') %>
<div id='flashContent'></div>
</body>
</html>

If you’re feeling extra lazy and want to have the flashContent div created automatically, then add a :create_div => true parameter to the swfobject call:

<html>
<head>
    <title>some page</title>
    <%= javascript_include_tag '/bin/swfobject' %>
</head>

<body>
<%= swfobject('/bin/YourSwf.swf', :create_div => true) %>
</body>
</html>

Only the first argument, the path to the .swf object, is required. The options and their defaults are:

:width => '100%',
:height => '100%',
:id => 'flashContent',
:version => nil,
:express_install_swf => nil,
:flash_vars => nil,
:params => nil,
:attributes => nil,
:create_div => false

A fully blown call to swfobject might look like this:

<%= swfobject('/bin/YourSwf.swf',
                         :flash_div => 'flashContent',
                         :width => '100%',
                         :height => '100%',
                         :version => '9.0.0',
                         :express_install_swf => '/bin/expressInstall.swf',
                         :flash_vars => 'flashVars',
                         :create_div => true
                        ) %>

Most of the options are pretty self-explanatory, but here’s some info on a couple of them:

:id gives the id of the div that the flash object will be created in. If :create_div is false, you must create the div yourself. If :create_div is true, it will be created for you.

:flash_vars, :options and :attributes can be passed in as either a Hash or a String. As a Hash they are translated to a Javascript Hash. As a String, they are assumed to represent the name of an existing Javascript variable. Here’s an example of passing in a Hash to flash_vars:

<html>
<head>
    <title>some page</title>
    <%= javascript_include_tag '/bin/swfobject' %>
</head>

<body>
<%= swfobject('/bin/YourSwf.swf', :create_div => true,
              :flash_vars => {'user_id' => @user.id, 'user_name' => @user.name}) %>
</body>
</html>

Here’s an example of passing in the name of a Javascript variable:

<html>
<head>
    <title>some page</title>
    <%= javascript_include_tag '/bin/swfobject' %>
</head>

<body>
<script>
  // Get the user information somehow, then add it to flashVars
  var flashVars = {user_id: user.id, user_name: user.name};
</script>
<%= swfobject('/bin/YourSwf.swf', :create_div => true, :flash_vars => 'flashVars') %>
</body>
</html>

Being able to pass in a name can come in handy if you want to pass in variables from the URL.

<html>
<head>
    <title>some page</title>
    <%= javascript_include_tag '/bin/swfobject' %>
</head>

<body>
<script>
	//Grab the flashVars from the URL search string.
	//This is not a perfect implementation: it will break, for example, if
	//you have an anchor tag, and it hasn't been tested with
	//URL encoded strings.

	var searchString = unescape(document.location.search);
	var flashVars = {};
	// strip off the leading '?' and split by '&'
	var nvPairs = searchString.replace(/^\?/, '').split("&");
	for (i = 0; i < nvPairs.length; i++)
	{
	  var nvPair = nvPairs[i].split(”=”);
	  var name = nvPair[0];
	  var value = nvPair[1];
	  flashVars[name] = value
	}
</script>
<%= swfobject(’/bin/YourSwf.swf’, :create_div => true, :flash_vars => ‘flashVars’) %>
</body>
</html>

That’s it. To get this, update your plugin to the latest version.

Scott Patten

Dima and I have been working hard not only on the Ruboss Framework, but also on a book which demonstrates how to use the framework correctly. This is finally ready for Beta release: http://manning.com/armstrong2/

The first chapter is freely available from http://www.manning-source.com/books/armstrong2/ch01_meap_enterprise.pdf.

Currently only 2 chapters are available, but many more will be added over the months ahead. We released this as early as possible, so that the framework documentation situation (which can currently only be described as “awful”) is improved.

Manning is pricing the PDF at $29.99 and the combo pack at $54.99. Frankly, if you were just buying the two chapters that are in the book, it would be borderline whether it would be worth it for you at this point–especially if you have followed along with the available free documentation. This is doubly-true since the first chapter is free. (If you bill your time hourly, however, it is probably still worth it.)

However, this is obviously not the finished product: this book is going to be the defining book about the Ruboss framework. By the end of the book, we will have included a discussion of BlazeDS and JRuby, Merb, Google App Engine, etc. (It’s not there yet, of course, since we haven’t even built the support for these into the framework yet!)

We want to emphasize two things:

1. The job of the book is to sell the framework, not the other way around. (The Ruboss Framework is the foundation of our company–which is currently 4 developers. It’s not something we’re building to sell books.)

2. We are going to continue to improve the free documentation, on the wiki and the blog. (The limiting factor on the free documentation is time, not any desire to not “compete” with the book.)

If you want to use the Ruboss framework on a project at work, having Enterprise Flexible Rails as a Manning book may help your chances, as it helps to counter the “lack of documentation” criticism. (Also, the Manning name adds some extra legitimacy for an Open Source project at such an early stage.)

The project in Enterprise Flexible Rails is going to be building an agile project management application intended for small teams. (Once again, I’m going to call this project Pomodo. No, it’s not the Pomodo from Flexible Rails: I just like the name!) The reason for this choice is entirely selfish: I want to build an application that my company can use once it’s done. We’ll write about our own dog food, as well as eating it…

As always, all feedback is very much appreciated.

Thanks,
Peter Armstrong and Dima Berastau

You can now force an order on attributes specified in db/model.yml by prefixing a line with - (standard YAML). This will produce flex model, generated view component, migrations, etc based on the exact order you specify. You can mix and match ordered attribute models with unordered attribute models.

Here’s an example:

project:
 - name*: string
 - notes: text
 - completed: boolean
 - user_id: integer
 - has_many: [tasks]

location:
 name*: string
 notes: text
 user_id: integer
 has_many: [tasks]

task:
 - name*: string
 - notes: text
 - completed: boolean
 - next_action: boolean
 - project_id: integer
 - location_id: integer
 - user_id: integer

This should produce ordered project and task artifacts and unordered location artifacts.

It is also possible to use a plain-text file to specify your models if you don’t like YAML for some reason. It should be located in db/model.txt. The format for it is quite simple, one model per line E.g.:

Project name:string notes:text completed:boolean user_id:integer has_many:tasks

If you are using plain text to store your models you should run ./script/multiscaffold instead of ./script/yamlscaffold

Dima and I have been working hard on the Ruboss Framework: a framework that aims to take Flex and Rails development to the next level by making the whole process a lot easier and more integrated.

We’re finally ready to release the first public Beta version. You can find the source code, getting started tutorial and more at the framework github page: http://github.com/ruboss/ruboss_framework/wikis

The documentation is very thin at the moment, but there’s more coming in the very near future.

Our ambition is to bring a RESTful, Rails-inspired approach to both Adobe Flex and AIR development. Obviously, this includes integrating with RESTful Rails controllers, with both XML over HTTP or AMF. You will also be able to use the local AIR database with virtually no changes to the code base.

Longer term plans may include a plugin for Merb, adaptors for Amazon SimpleDB, Google App Engine, etc — basically, anything that has or can be exposed with a RESTful API that we can talk to from a Ruboss-using Flex application.

We are using the Ruboss Framework on projects of varying complexity and have been very happy with the productivity improvements. But since we are the framework authors, this is to be expected.

All feedback is very much appreciated.

We hope that you’ll find using the Ruboss framework enjoyable.

Peter Armstrong and Dima Berastau
